소신호 트랜지스터

BC807WActive

BC807W PNP bipolar transistor packaged in SOT-323 package suitable for low-power fast surface mounting. The product is designed for general amplifier applications in industries such as industrial power management and automotive electronics.

데이터시트 지금 문의하세요

전기적 매개변수

Part Number BC807W

Package SOT-323

AEC-Q101 QualifiedNo

Type PNP

PCM(W) 0.2

IC(A) -0.5

VCBO [Max] (V) -50

VCEO [Max] (V) -45

VEBO [Max] (V) -5

hFE [Min] 100

hFE [Max] 600

fT [Min] (MHz) 80

TJ (°C) -55~+150

Status Active

제품 특징

Complementary to BC817W Ideally suited for automatic insertion Epitaxial planar die construction
