폴리머 ESD 억제제

SPE0402B24Active

The SPE0402B24 ESD suppressor product utilize polymer technology, featuring ultra-low capacitance and a compact form factor, which help protect sensitive electronic devices from ESD damage. They effectively complement integrated circuit protection products and are particularly suitable for low-voltage, high-speed applications that emphasize low capacitance. This new technology is highly effective for data ports using high-speed protocols such as USB 2.0, IEEE 1394, HDMI, and DVI.

데이터시트 지금 문의하세요

전기적 매개변수

Part Number SPE0402B24

Status Active

VR [Max] (V) 24

Vc [Typ] (V) 35

VT [Typ] (V) 300

IL [Typ] (uA) 0.1

Vesd [Contact] (KV) 15

Vesd [Air] (KV) 25

Cj [max] (pF) 0.05

Package SPE0402

Size (mm) 1.05x0.55x0.25

제품 특징

ESD protection for high speed data lines to IEC61000-4-2 ESD contact discharge typical 8KV, max 15KV ESD air discharge typical 15KV, max 25KV
